Trailer Mounted Combos
2 Ton Combo
The Ray-Tech 2 Ton Combo is our smallest trailer mounted combo option featuring a 2 ton reclaimer and a 6’L x 8’W heating chamber.
The 2 Ton Combo features a 6’L x 8’W infrared heating chamber mounted on the rear of a dual axle trailer and a 2 ton reclaimer mounted in the middle of the trailer. This has been our most popular starter unit for years due to the capacity and maneuverability.
- Basics Package – Time Delay System (TDS) / LED Work Lights / LED Arrow Board.
- Pro Package – Roller or Compactor Platform with Heavy Duty Winch / Aluminum Wind Guards / Spare Wheel / Cone Storage.
- Roller – Single Drum Walk Behind Vibratory Roller (Bomag BW55E).
- Color – Custom Color (Standard is Ray-Tech Safety Lime Green & Black).
- Two 24V brushless blower motors.
- Locking battery box containing batteries, charging system and all controls.
- Easy manual ignition with a customer supplied hand held torch.
- Completely stainless steel heating chamber.
- Heavy duty electric winch to raise and lower chamber.
- Ray-Tech unique heating converters for fastest and most efficient heating.
- Four 100 lb propane cylinders to feed heating chamber.
- One 100 lb and one 60 lb propane cylinder to feed reclaimer.
- 2 ton reclaimer.
- Two manual top loading doors on reclaimer.
- Two manual shovel doors; one on each side of reclaimer.
- Heavy duty steel frame.
- Two 6,000 lb torflex axles.
- LED trailer lighting throughout.
- Length: 15’ 10″
- Width: 8′ 0″
- Height: 8′ 10″
- Chamber Length: 6’L
- Chamber Width: 8’W
- Weight (Empty): 6,200 lbs
- Weight (GVW) 11,000 lbs
3 Ton Combo
The Ray-Tech 3 Ton Combo is our mid-sized offering of a combo trailer featuring a 3 ton reclaimer and a 6’L x 8’W heating chamber.
The 3 Ton Combo features a 6’L x 8’W infrared heating chamber mounted on the rear of a dual axle trailer and a 3 ton reclaimer mounted in the middle of the trailer. This is a perfect machine for most repair work.
- Basics Package – Time Delay System (TDS) / LED Work Lights / LED Arrow Board.
- Pro Package – Roller or Compactor Platform with Heavy Duty Winch / Aluminum Wind Guards / Spare Wheel / Cone Storage.
- Roller – Single Drum Walk Behind Vibratory Roller (Bomag BW55E).
- Color – Custom Color (Standard is Ray-Tech Safety Lime Green & Black).
- Two 24V brushless blower motors.
- Locking battery box containing batteries, charging system and all controls.
- Easy manual ignition with a customer supplied hand held torch.
- Completely stainless steel heating chamber.
- Heavy duty electric winch to raise and lower chamber.
- Ray-Tech unique heating converters for fastest and most efficient heating.
- Four 100 lb propane cylinders to feed heating chamber.
- One 100 lb and one 60 lb propane cylinder to feed reclaimer.
- 3 ton reclaimer.
- Two manual top loading doors on reclaimer.
- Four manual shovel doors; two on each side of reclaimer.
- Heavy duty steel frame.
- Two 8,000 lb torflex axles.
- LED trailer lighting throughout.
- Length: 17’ 0″
- Width: 8′ 0″
- Height: 9′ 0″
- Chamber Length: 6’L
- Chamber Width: 8’W
- Weight (Empty): 7,630 lbs
- Weight (GVW): 15,000 lbs
4 Ton Combo
The Ray-Tech 4 Ton Combo is our largest trailer mounted combo featuring a 4 ton reclaimer and a 6’L x 8’W heating chamber.
The 4 Ton Combo features a 6’L x 8’W infrared heating chamber mounted on the rear of a dual axle trailer and a 4 ton reclaimer mounted in the middle of the trailer. This is a favorite of large infrared repair companies as well as utility companies who need the larger amount of asphalt during the day.
- Basics Package – Time Delay System (TDS) / LED Work Lights / LED Arrow Board.
- Pro Package – Roller or Compactor Platform with Heavy Duty Winch / Aluminum Wind Guards / Spare Wheel / Cone Storage.
- Roller – Single Drum Walk Behind Vibratory Roller (Bomag BW55E).
- Color – Custom Color (Standard is Ray-Tech Safety Lime Green & Black).
- Two 24V brushless blower motors.
- Locking battery box containing batteries, charging system and all controls.
- Easy manual ignition with a customer supplied hand held torch.
- Completely stainless steel heating chamber.
- Heavy duty electric winch to raise and lower chamber.
- Ray-Tech unique heating converters for fastest and most efficient heating.
- Four 100 lb propane cylinders to feed heating chamber.
- One 100 lb and one 60 lb propane cylinder to feed reclaimer.
- 4 ton reclaimer.
- Two manual top loading doors on reclaimer.
- Four manual shovel doors; two on each side of reclaimer.
- Heavy duty steel frame.
- Two 10,000 lb torflex axles.
- LED trailer lighting throughout.
- Length: 17’ 0″
- Width: 8′ 0″
- Height: 9′ 0″
- Chamber Length: 6’L
- Chamber Width: 8’W
- Weight (Empty): 8,100 lbs
- Gross Weight: 16,660 lbs
Founded with the mission to deliver the highest quality infrared asphalt equipment, Ray-Tech has set the industry standard for durability, efficiency, and performance. Our machines are built to withstand tough conditions and deliver long-lasting results that contractors and municipalities can rely on.
When you need proven performance, choose Ray-Tech.
